    Excavator tilting quick hitch attachments, excavator fast connector

    Ask Lasest Price
    Brand Name : PA TECH
    Model Number : JX K-MINI, JXK-02, JXK-04,JXK-06, JXK-08, JXK-10, JXK-17
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 200-500 sets
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    Excavator tilting quick hitch attachments, excavator fast connector

    Excavator tilting quick hitch attachments, excavator fast connector


    Product Features of Quick Hitches Coupler, Excavator Fast Connector


    (1) Integrative mechanical design of high strength manganese steel and structure is durable and suitable for assembly requirements of excavators of various tonnages.
    (2) Electric switches are installed in the cab to replace the high-cost oil pressure by electricity, which is convenient for the driver to operate.0
    (3) Each cylinder is equipped with a hydraulic control one-way v0alve and a mechanical locking safety device to ensure that the fast connector can work normally when the oil circuit and circuit are cut off.
    (4) Each fast connector is equipped with safety pin protection system to ensure that the fast connector can work normally and play the role of "double insurance" when the oil cylinder of the fast connector fails.

    Product Parameters of Quick Hitches Coupler, Excavator Fast Connector


    ModelUnitJX K-MINIJX K-02JX K-04JX K-06JX K-08JX K-10JX K-17
    Length Cmm300-450550-595581-610795-825888-980980-10601005-1150
    Height Gmm246312310388492574558-610
    Width Bmm175258-263270-280353-436449-483543-568606-663
    Pins Center Distance Dmm80-150230-270290-360380-420460-480473-540550-620
    Arm Width Amm80-140155-170180-200232-315306-340375-411416-469
    Cylinder Stroke Emm95-200200-300300-350340-440420-510460-560600-650
    Vertical Pins Center Dist Ancmm159200200260325385360
    Weightkg3060-7080-90220-250400-430500-650700-1000
    Working Pressurekg/cm²200200200200200200200
    Necessary Flowl/min10-2010-2010-2010-2010-2010-2010-20
    Excavatorton1.5-44-75-89-1917-2323-3033-45

    Excavator tilting quick hitch attachments, excavator fast connector


    Packing & Delivery of Quick Hitches Coupler, Excavator Fast Connector



    Workshop Show of Quick Hitches Coupler, Excavator Fast Connector



    Factory Show of Quick Hitches Coupler, Excavator Fast Connector



    Our Service:


    1-- Six months warranty of products.

    2-- Online consultation and answering.
    3-- Free customization.
    4-- Delivery within 15 days.


    If you have any question or want to know more about our excavator attachments,please feel free to send an inquiry to us!We will do the best to help you!
